Description
10.1" Floating HD display with capacitive touch screen
European Garmin navigation built in
Vehicle size profiling capabilities
Camper contact by NKC, ACSI - databases built in
DAB / FM tuner
Wireless car play
Wireless android auto
4 camera inputs
Hi res audio compatible
DSP and time alignment built in
Steering wheel remote control adapter & OEM Display interface ready
-
Key Features
10.1" HD (1280 x 720px) LCD display for sharp, high-contrast images, vivid colors and superior wide viewing angle Floating Panel Mechanism with 3-way Position Adjustment. Wi-Fi built-in for convenient wireless connection with a compatible smartphone. Supports CarPlay & Android Auto wirelessly or connected via USB. Supports Wireless Mirroring for Android including 2-way touch control capability. Equipped with the industry leading Garmin navigation system offering a variety of display options to make your driving easier Routes suggested according to the RV, Truck or Car Profile. Camper contact by NKC, ACSI & HERE campsites. 3 Years Garmin map care. DAB+ radio tuner for noise & interference free reception and crystal-clear digital stereo sound Bluetooth(R) Wireless Technology for hands-free calls and music streaming. (Available functions depend on cell phone). Compatible with Hi-Res Audio which provides greater sound clarity and detail than standard compressed digital audio formats. Featuring 4 camera inputs allow for the utmost in convenience, flexibility, and safety. Digital Sound Processor, Time Alignment & 13-Band EQ for optimal sound tuning enhancements. Steering wheel remote control adapter & OEM Display interface ready (Optional car specific interface required). General Features
DIN Size 2 DIN Security Code Function ( user set) Yes Selectable GUI Background Wallpaper Yes Key Illumination Variable color Rotary Encoder & Control Knob Yes Touch sensor Yes Installer Memory Yes Back-up Memory Yes Attenuator with Smooth Volume Return Yes Optional IR remote controller Yes, KCA-RCDV340 Digital Clock (24H) Yes Built-in Bluetooth Yes DAB Tuner Built-in Yes Wifi built-in Yes Made for iPod Yes Works with Apple CarPlay Yes Works Wireless with Apple CarPlay Yes Works with Android Auto Yes Works Wireless with Android Auto Yes Wireless Mirroring for Android Yes HDMI input for video playback Dashcam Link Yes
Multimedia GUI Features
Software updates (SoC) via USB Graphics Type Graphics Top Menu Customize Yes Multi Widgets Multi (up to 4), Clock, Weather & Photo Frame Widget Animation Yes Multi touch function Yes, (Garmin navigation) R-CAM interrupt Yes R-CAM Caution On Screen Display Yes R-CAM Parking Guide Lines Yes, customizable Front Camera Interruption Yes Front view camera mirror Yes DashCam Control Yes Menu text in selectable language 22 languages: English(UK)(Default), English(US), Spanish, French, German, Italian, Dutch, Russian, Portuguese, Chinese (Simplified), Chinese (Traditional), Thai, Turkish, Arabic, Persian, Hebrew, Greek, Malaysian, Indonesian, Polish, Czech, Hungarian.
Monitor Features
In-Dash/On-Dash In-Dash LCD type 10.1 inch Wide HD screen (1280 x 720p) LCD backlight LED Display Mode 3 Mode (Full(default)/Auto/Normal) Screen Adjustments Noon/Night Mem/Brightness/Tint/Colour/Contrast Dimmer function Manual/Sync/Navi Sync Dimmer Level Sync / On / Off Visual Source Mode Mirorring/CarPlay/Android Auto. Touch Panel Capacitive Display film Anti-Fingerprint / Anti-Reflection / Anti-Glare) High Definition Display Yes Mechanism type Floating screen Tilt mechanism control -10° ~ +45° Forward/backward mechanism control 0 ~ 22mm (fixed by screws) Up/Down mechanism control 0 ~ 39mm (fixed by screws) NTSC/PAL judge Yes (Auto) Display Off Mode Yes
Audio features
Max. Output Power 4 x 50W Pre-out 3RCA: Front/Rear/Subwoofer Pre-out Output Level 5V Volume Offset Yes 2 Zone Control Yes Att.(-20dB) with smooth Volume Return Yes
Multimedia DSP Features
DSP Chip AK7738 Position Control Yes Position Preset 4 Presets Position Cabin Size Yes Parametric Equalizer Yes Parametric Equalizer Bands 13 Preseted Parametric Equalizer Settings Yes Manual Parametric Equalizer Settings Yes High Pass Filter (HPF) Yes Low Pass Filter (LPF) Yes (Non-Fading) 3-Way X'Over Yes Source DSP Memory Yes Channel Level Control Yes Space Enhancer Yes Supreme Yes Realizer Yes Loudness Yes Stage EQ Yes Bass Boost Yes Drive EQ+ Yes Speaker Size & Location Control Yes Listening postion control / Time Alignment Yes
Video Features
Audio Video Output Yes, Video: RCA, Audio: mini-jack Audio/Video Input Yes, AV-input or Camera input (Selectable) HDMI input Yes Video-In for Rear-view Camera 1 Detection Mode Rear View Camera Reverse sensor wire Parking Guide Line Yes
Tuner Features
FM Reception Yes FM Stereo / Mono Selector Yes AM (MW/LW) Reception Yes Tuning mode Auto1/Auto2/Manual Up/Down Seek/Scan Yes Tuner Presets (FM/AM) 20 Presets (15FM / 5AM) Automatic Memory Entry (AME) Yes Radio Data System Yes Radio Text Plus Yes Traffic Information Yes Local search Yes Auto TP search Yes Enhanced Other Networks Function (EON) Yes Program Type Function (PTY) Yes
